Technical data
Luminaire power
7 [W]
Luminaire luminous flux
290 - 310 [lm]
Type of diffuser/plate
PLX
Distribution angle
82°
Color temperature
3000 K, 4000 K
Color rendering index
90
Lifetime Lxx Bxx
L80B10@50.000h
Diameter D
70 mm
The color of the housing
White RAL9016, Black RAL9005, Gray RAL9006, Black RAL9005/ White RAL9016
IP
IP20
Type of control
ON/OFF
Supply voltage
220-240 VAC, 50/60 Hz
[mm]
For download
Project tools
Documents

You are about to download a large amount of files.

It may take a while. Do you want to continue?

Installation
Shape of the luminaire
Type of diffuser/plate
The color of the housing
The color of the light
IP
Diameter [mm]
Luminaire power [W]
Luminaire luminous flux [lm]
Type of control
Other
Apply filters
Filters
Code Length L [mm] Luminaire power [W] Luminaire luminous flux [lm] Type of diffuser/plate The color of the housing The color of the light Type of control Other Files
Bayo 70 Surface L-shape PLX ST/930, H=100mm, RAL9016
02.201.2001.01.930 		7 290 PLX White RAL9016 930 ON/OFF L-shape
Bayo 70 Surface L-shape PLX ST/940, H=100mm, RAL9016
02.201.2001.01.940 		7 310 PLX White RAL9016 940 ON/OFF L-shape
Bayo 70 Surface L-shape PLX ST/930, H=100mm, RAL9006
02.201.2001.02.930 		7 290 PLX Gray RAL9006 930 ON/OFF L-shape
Bayo 70 Surface L-shape PLX ST/940, H=100mm, RAL9006
02.201.2001.02.940 		7 310 PLX Gray RAL9006 940 ON/OFF L-shape
Bayo 70 Surface L-shape PLX ST/930, H=100mm, RAL9005
02.201.2001.03.930 		7 290 PLX Black RAL9005 930 ON/OFF L-shape
Bayo 70 Surface L-shape PLX ST/940, H=100mm, RAL9005
02.201.2001.03.940 		7 310 PLX Black RAL9005 940 ON/OFF L-shape
Bayo 70 Surface L-shape PLX ST/930, H=100mm, RAL9005/RAL9016
02.201.2001.31.930 		7 290 PLX Black RAL9005/ White RAL9016 930 ON/OFF L-shape
Bayo 70 Surface L-shape PLX ST/940, H=100mm, RAL9005/RAL9016
02.201.2001.31.940 		7 310 PLX Black RAL9005/ White RAL9016 940 ON/OFF L-shape
Bayo 70 Surface L-shape PLX ST/930, H=150mm, RAL9016
02.201.2002.01.930 		7 290 PLX White RAL9016 930 ON/OFF L-shape
Bayo 70 Surface L-shape PLX ST/940, H=150mm, RAL9016
02.201.2002.01.940 		7 310 PLX White RAL9016 940 ON/OFF L-shape
Bayo 70 Surface L-shape PLX ST/930, H=150mm, RAL9006
02.201.2002.02.930 		7 290 PLX Gray RAL9006 930 ON/OFF L-shape
Bayo 70 Surface L-shape PLX ST/940, H=150mm, RAL9006
02.201.2002.02.940 		7 310 PLX Gray RAL9006 940 ON/OFF L-shape
Bayo 70 Surface L-shape PLX ST/930, H=150mm, RAL9005
02.201.2002.03.930 		7 290 PLX Black RAL9005 930 ON/OFF L-shape
Bayo 70 Surface L-shape PLX ST/940, H=150mm, RAL9005
02.201.2002.03.940 		7 310 PLX Black RAL9005 940 ON/OFF L-shape
Bayo 70 Surface L-shape PLX ST/930, H=150mm, RAL9005/RAL9016
02.201.2002.31.930 		7 290 PLX Black RAL9005/ White RAL9016 930 ON/OFF L-shape
Bayo 70 Surface L-shape PLX ST/940, H=150mm, RAL9005/RAL9016
02.201.2002.31.940 		7 310 PLX Black RAL9005/ White RAL9016 940 ON/OFF L-shape
Bayo 70 Surface L-shape PLX ST/930, H=250mm, RAL9016
02.201.2003.01.930 		7 290 PLX White RAL9016 930 ON/OFF L-shape
Bayo 70 Surface L-shape PLX ST/940, H=250mm, RAL9016
02.201.2003.01.940 		7 310 PLX White RAL9016 940 ON/OFF L-shape
Bayo 70 Surface L-shape PLX ST/930, H=250mm, RAL9006
02.201.2003.02.930 		7 290 PLX Gray RAL9006 930 ON/OFF L-shape
Bayo 70 Surface L-shape PLX ST/940, H=250mm, RAL9006
02.201.2003.02.940 		7 310 PLX Gray RAL9006 940 ON/OFF L-shape
1
2
Accessories
Suspensions
Electric suspension Ø70mm, 3x0.75mm2, L=1200mm, ON/OFF, cable with braid
Code
Name
12.201.3011.11
Electric suspension Ø70mm, 3x0.75mm2, L=1200mm, ON/OFF, cable with braid White, White RAL9016
12.201.3011.13
Electric suspension Ø70mm, 3x0.75mm2, L=1200mm, ON/OFF, cable with braid White, Black RAL9005
12.201.3011.33
Electric suspension Ø70mm, 3x0.75mm2, L=1200mm, ON/OFF, cable with braid Black, Black RAL9005
12.201.3011.31
Electric suspension Ø70mm, 3x0.75mm2, L=1200mm, ON/OFF, cable with braid Black, White RAL9016
Electric suspension Ø70mm, 3x0.75mm2, L=3000mm, ON/OFF, cable with braid
Code
Name
12.201.3012.11
Electric suspension Ø70mm, 3x0.75mm2, L=3000mm, ON/OFF, cable with braid White, White RAL9016
12.201.3012.31
Electric suspension Ø70mm, 3x0.75mm2, L=3000mm, ON/OFF, cable with braid Black, White RAL9016
12.201.3012.13
Electric suspension Ø70mm, 3x0.75mm2, L=3000mm, ON/OFF, cable with braid White, Black RAL9005
12.201.3012.33
Electric suspension Ø70mm, 3x0.75mm2, L=3000mm, ON/OFF, cable with braid Black, Black RAL9005
Electric suspension Ø70mm, 3x0.75mm2, L=5000mm, ON/OFF, cable with braid
Code
Name
12.201.3013.11
Electric suspension Ø70mm, 3x0.75mm2, L=5000mm, ON/OFF, cable with braid White, White RAL9016
12.201.3013.31
Electric suspension Ø70mm, 3x0.75mm2, L=5000mm, ON/OFF, cable with braid Black, White RAL9016
12.201.3013.13
Electric suspension Ø70mm, 3x0.75mm2, L=5000mm, ON/OFF, cable with braid White, Black RAL9005
12.201.3013.33
Electric suspension Ø70mm, 3x0.75mm2, L=5000mm, ON/OFF, cable with braid Black, Black RAL9005
