Technical data For download List of products Contact
Smart
Eco-friendly
Modern
User friendly
Stylish
Technical data
Luminaire power
9 - 48 [W]
Luminaire luminous flux
1100 - 7000 [lm]
Type of diffuser/plate
PLX, Louvre
Distribution angle
60°, 90°
Color temperature
3000 K, 4000 K
Color rendering index
80
Lifetime Lxx Bxx
L80B10@75.000h, L90B10@60.000h
Length L
612, 892, 1172, 1452, 1732 mm
Diameter D
80 mm
The color of the housing
White RAL9016, Black RAL9005, Gray RAL9006
IP
IP65
Type of control
ON/OFF, DALI
Supply voltage
230V AC 50Hz
Other
the luminaire is delivered complete with a 500mm long power cable
[mm]
For download
Project tools
Documents

You are about to download a large amount of files.

It may take a while. Do you want to continue?

Type of assembly
Shape of the luminaire
Type of diffuser/plate
The color of the housing
The color of the light
IP
Length [mm]
Diameter [mm]
Luminous flux level
Luminaire power [W]
Luminaire luminous flux [lm]
Type of control
Apply filters
Filters
Code Luminous flux level Luminaire power [W] Luminaire luminous flux [lm] Length L [mm] Type of diffuser/plate The color of the housing The color of the light Type of control Files
Vibrio 80 Wall Adjustable PLX ST/830, L=612mm, IP65, 220mA, RAL9016
07.077.4102.01.830 		ST 9 1250 612 PLX White RAL9016 830 ON/OFF
Vibrio 80 Wall Adjustable PLX ST/830, L=612mm, IP65, 220mA, DALI, RAL9016
07.077.4102.01.830.DALI 		ST 9 1250 612 PLX White RAL9016 830 DALI
Vibrio 80 Wall Adjustable PLX ST/840, L=612mm, IP65, 220mA, RAL9016
07.077.4102.01.840 		ST 9 1300 612 PLX White RAL9016 840 ON/OFF
Vibrio 80 Wall Adjustable PLX ST/840, L=612mm, IP65, 220mA, DALI, RAL9016
07.077.4102.01.840.DALI 		ST 9 1300 612 PLX White RAL9016 840 DALI
Vibrio 80 Wall Adjustable PLX ST/830, L=612mm, IP65, 220mA, RAL9006
07.077.4102.02.830 		ST 9 1250 612 PLX Gray RAL9006 830 ON/OFF
Vibrio 80 Wall Adjustable PLX ST/830, L=612mm, IP65, 220mA, DALI, RAL9006
07.077.4102.02.830.DALI 		ST 9 1250 612 PLX Gray RAL9006 830 DALI
Vibrio 80 Wall Adjustable PLX ST/840, L=612mm, IP65, 220mA, RAL9006
07.077.4102.02.840 		ST 9 1300 612 PLX Gray RAL9006 840 ON/OFF
Vibrio 80 Wall Adjustable PLX ST/840, L=612mm, IP65, 220mA, DALI, RAL9006
07.077.4102.02.840.DALI 		ST 9 1300 612 PLX Gray RAL9006 840 DALI
Vibrio 80 Wall Adjustable PLX ST/830, L=612mm, IP65, 220mA, RAL9005
07.077.4102.03.830 		ST 9 1250 612 PLX Black RAL9005 830 ON/OFF
Vibrio 80 Wall Adjustable PLX ST/830, L=612mm, IP65, 220mA, DALI, RAL9005
07.077.4102.03.830.DALI 		ST 9 1250 612 PLX Black RAL9005 830 DALI
Vibrio 80 Wall Adjustable PLX ST/840, L=612mm, IP65, 220mA, RAL9005
07.077.4102.03.840 		ST 9 1300 612 PLX Black RAL9005 840 ON/OFF
Vibrio 80 Wall Adjustable PLX ST/840, L=612mm, IP65, 220mA, DALI, RAL9005
07.077.4102.03.840.DALI 		ST 9 1300 612 PLX Black RAL9005 840 DALI
Vibrio 80 Wall Adjustable PLX HO/830, L=612mm, IP65, 400mA, RAL9016
07.077.4103.01.830 		HO 16 2250 612 PLX White RAL9016 830 ON/OFF
Vibrio 80 Wall Adjustable PLX HO/830, L=612mm, IP65, 400mA, DALI, RAL9016
07.077.4103.01.830.DALI 		HO 16 2250 612 PLX White RAL9016 830 DALI
Vibrio 80 Wall Adjustable PLX HO/840, L=612mm, IP65, 400mA, RAL9016
07.077.4103.01.840 		HO 16 2400 612 PLX White RAL9016 840 ON/OFF
Vibrio 80 Wall Adjustable PLX HO/840, L=612mm, IP65, 400mA, DALI, RAL9016
07.077.4103.01.840.DALI 		HO 16 2400 612 PLX White RAL9016 840 DALI
Vibrio 80 Wall Adjustable PLX HO/830, L=612mm, IP65, 400mA, RAL9006
07.077.4103.02.830 		HO 16 2250 612 PLX Gray RAL9006 830 ON/OFF
Vibrio 80 Wall Adjustable PLX HO/830, L=612mm, IP65, 400mA, DALI, RAL9006
07.077.4103.02.830.DALI 		HO 16 2250 612 PLX Gray RAL9006 830 DALI
Vibrio 80 Wall Adjustable PLX HO/840, L=612mm, IP65, 400mA, RAL9006
07.077.4103.02.840 		HO 16 2400 612 PLX Gray RAL9006 840 ON/OFF
Vibrio 80 Wall Adjustable PLX HO/840, L=612mm, IP65, 400mA, DALI, RAL9006
07.077.4103.02.840.DALI 		HO 16 2400 612 PLX Gray RAL9006 840 DALI
1
2 3 4 5
...
12
